起搏器患者进行磁共振检查的安全性研究

褚松筠; 王玉玲; 蒋捷; 邱建星; 陈尔冬; 金汉; 贺鹏康; 盛琴慧; 周菁

doi:10.13201/j.issn.1001-1439.2020.11.009

起搏器患者进行磁共振检查的安全性研究

- 1 北京大学第一医院心内科(北京, 100034);
- 2 北京大学第一医院影像科
基金项目:
北京大学第一医院青年临床研究基金(No:2017CR20)

详细信息

通讯作者: 褚松筠,E-mail:cstellar@sina.com

中图分类号: R541.7

收稿日期: 2020-07-09

Safety assessment for magnetic resonance imaging in patients with pacemakers

- 1 Department of Cardiology, Peking University First Hospital, Beijing, 100034, China;
- 2 Department of Medical Imaging, Peking University First Hospital

More Information

Corresponding author: CHU Songyun, E-mail: cstellar@sina.com

Received Date: 09 July 2020

摘要

摘要: 目的:调查植入磁共振(MR)条件兼容起搏器的患者进行MR检查的即刻和长期安全性。方法:回顾2011—2019年在我院植入MR兼容起搏器的患者287例,随访器械相关的主要安全性终点(电量提前耗竭,导线功能异常或起搏失夺获)和临床安全性主要终点(死亡,心脏停搏＞5 s,持续性室性心律失常)的发生。比较MR检查前后参数变化,及与对照人群基线和长期起搏参数的改变。结果:所有患者在随访中均无临床终点事件和器械相关功能异常发生。共11例患者接受了MR检查,扫描部位为头颅(9例),腰椎(1例),颌面部(1例),中位扫描时间20(10~34) min。MR后即刻、MR后1~3个月患者起搏参数及电池电压较MR前无显著改变。进行MR与未进行MR的患者基线和慢性期起搏参数、电池电压无显著差异(均P＞0.05)。结论:植入MR兼容起搏器患者严格按照流程进行MR前准备和程控,可以安全进行推荐场强和部位的MR检查。
- 磁共振 /
- 起搏器 /
- 安全性
Abstract: Objective: To determine the safety in patients with MR-conditional device to undergo MR imaging. Method: Study cohort was established including 287 patients with MR-conditional pacemakers implantation in our center between 2011 and 2019. Primary device-related endpoints(premature exhaustion of the battery, malfunction of the leads or loss of capture) and clinical endpoints(death, cardiac arrest＞5 seconds, and the occurrence of sustained ventricular arrhythmias) were collected during follow-up. On interrogation, post-MR results of the device parameters were compared with reference to the data prior to the MR, as well as to patients who did not undergo MR examination. Result: No clinical or device related events occured during the MR examination and during follow up. A total of 11 patients received MR examination, including 9 cases of skull imaging, 1 case of lumbar imaging and 1 case of maxillofacial imaging with the median scanning time of 20(10-34) minutes. Pacing parameters and battery voltage showed no significant changes in before and after MR. No changes of pacemaker function were observed between the patients undergoing MR and control(all P＞0.05).Conclusion: With adherence to a standardized protocol for MR imaging preparation and programming, MR with certain field intensity and locations could safely be performed in patients with MR-conditional pacemakers.
- magnetic resonance imaging /
- pacemaker /
- safety

HTML全文

参考文献(18)

[1]	熊浩,富青,赵洁,等.1.5T磁共振T1mapping技术评价扩张型心肌病弥漫性纤维化的研究[J].临床心血管病杂志,2020,36(7):652-657.
[2]	匡建梅,徐全民.血液检验指标在无症状心肌缺血患者诊断中的价值[J].临床血液学杂志,2020,33(2):93-96.
[3]	Nordbeck P,Ertl G,Ritter O.Magnetic resonance imaging safety in pacemaker and implantable cardioverter defibrillator patients:how far have we come?[J].Eur Heart J,2015,36(24):1505-1111.
[4]	Higgins JV,Sheldon SH,Watson RE Jr,et al."Power-on resets" in cardiac implantable electronic devices during magnetic resonance imaging[J].Heart Rhythm,2015,12(3):540-544.
[5]	Bailey WM,Mazur A,McCotter C,et al.Clinical safety of the ProMRI pacemaker system in patients subjected to thoracic spine and cardiac 1.5-T magnetic resonance imaging scanning conditions[J].Heart Rhythm,2016,13(2):464-471.
[6]	Russo RJ,Costa HS,Silva PD,et al.Assessing the risks associated with MRI in patients with a pacemaker or defibrillator[J].N Engl J Med,2017,376(8):755-764.
[7]	Shah AD,Morris MA,Hirsh DS,et al.Magnetic resonance imaging safety in nonconditional pacemaker and defibrillator recipients:A meta-analysis and systematic review[J].Heart Rhythm,2018,15(7):1001-1008.
[8]	中华医学会影像技术分会,中华医学会放射学分会.MRI检查技术专家共识[J].中华放射学杂志,2016,50(10):724-739.
[9]	Chow GV,Nazarian S.MRI for patients with cardiac implantable electrical devices[J].Cardiol Clin,2014,32(2):299-304.
[10]	刘兴鹏,田颖,任明,等.我国接受心血管植入型电子器械治疗的老年患者磁共振检查的需求调查[J].中华心律失常学杂志,2015,19(4):268-270.
[11]	中华医学会放射学分会质量管理与安全管理学组,中华医学会放射学分会磁共振成像学组.磁共振成像安全管理中国专家共识[J].中华放射学杂志,2017,51(10):725-731.
[12]	Williamson BD,Gohn DC,Ramza BM,et al.Real-world evaluation of magnetic resonance imaging in patients with a magnetic resonance imaging conditional pacemaker system:results of 4-year prospective follow-up in 2,629 patients[J].JACC Clin Electrophysiol,2017,3(11):1231-1239.
[13]	Seewöster T,Löbe S,Hilbert S,et al.Cardiovascular magnetic resonance imaging in patients with cardiac implantable electronic devices:best practice and real-world experience[J].Europace,2019,21(8):1220-1228.
[14]	武敏,于海波,梁延春,等.心脏起搏器植入患者进行核磁共振扫描安全性研究[J].临床军医杂志,2019,47(2):153-155.
[15]	Sabzevari K,Oldman J,Herrey AS,et al.Provision of magnetic resonance imaging for patients with'MR-conditional'cardiac implantable electronic devices:an unmet clinical need[J].Europace,2017,19(3):425-431.
[16]	Celentano E,Caccavo V,Santamaria M,et al.Access to magnetic resonance imaging of patients with magnetic resonance-conditional pacemaker and implantable cardioverter-defibrillator systems:results from the Really ProMRI study[J].Europace,2018,20(6):1001-1009.
[17]	Indik JH,Gimbel JR,Abe H,et al.2017 HRS expert consensus statement on magnetic resonance imaging and radiation exposure in patients with cardiovascular implantable electronic devices[J].Heart Rhythm,2017,14(7):e97-e153.
[18]	Hilbert S,Jahnke C,Loebe S,et al.Cardiovascular magnetic resonance imaging in patients with cardiac implantable electronic devices:a device-dependent imaging strategy for improved image quality[J].Eur Heart J Cardiovasc Imaging,2018,19(9):1051-1061.
