摘要: 目的 通过单中心长期随访，探讨永久希氏束起搏(His-bundle pacing，HBP)的长期有效性和安全性。方法 回顾性分析2018年8月—2019年12月于西安交通大学第二附属医院心血管内科接受永久起搏器植入的患者，其中58例行HBP，66例行右室间隔部起搏。观察术中QRS波时限、手术成功率，随访术后即刻、1年、2年、3年时的心室起搏阈值、阻抗、感知以及手术相关并发症。结果 67例患者拟行HBP，最终有58例植入成功(成功率85.6%)，HBP组术前QRS波时限(95.5±18.5) ms，术后QRS波时限(103.6±15.1) ms，差异无统计学意义。右室间隔起搏组术前QRS波时限(101.8±26.9) ms，术后QRS波时限(145.2±11.8) ms，明显延长(P < 0.05)。术后即刻及1年、2年、3年HBP组心室起搏阈值分别为(0.83±0.43) V/0.4ms、(0.97±0.31) V/0.4ms、(1.11±0.39) V/0.4ms、(1.28±0.56) V/0.4ms，阈值逐年升高(P < 0.001)，2例阈值升高至2.5 V/1.0ms，未发生失夺获。HBP组1例患者发生囊袋感染，两组术后随访均无电极脱位、心脏穿孔等其他并发症发生。结论 HBP是最具生理性的起搏方式，但是其长期随访有起搏阈值升高风险。Abstract: Objective To investigate the long-term efficacy and safety of permanent His-bundle pacing(HBP).Methods In a retrospective study, patients who underwent permanent pacemaker implantation at the Department of Cardiology, Second Affiliated Hospital of Xi'an Jiaotong University between August 2018 and December 2019 were enrolled. Among them, 58 patients received His bundle pacing(HBP), while 66 patients received right ventricular septal pacing. The QRS durations and implantation success rate were observed. The threshold, impedance, R wave sensing, and related complications were monitored immediately post-implantation as well as at 1-year, 2-year, and 3-year after operation.Results Of 67 patients who planned to undergo HBP, 58 were successfully implanted(85.6% success rate). The preoperative QRS duration was 95.5±18.5 ms and postoperative QRS duration was 103.6±15.1 ms in the HBP group, with no statistical significance. In the right ventricular septal pacing group, the duration of QRS wave before operation was(101.8±26.9) ms, and the duration of QRS wave after operation was(145.2±11.8) ms(P < 0.05). The ventricular pacing thresholds were(0.83±0.43) V/0.4ms, (0.97±0.31) V/0.4ms, (1.11±0.39) V/0.4ms and(1.28±0.56) V/0.4ms in the HBP group immediately and at 1, 2 and 3 years after surgery, respectively, and the thresholds were increased year by year(P < 0.001). The threshold increased to 2.5V /1.0ms in 2 cases, and no loss occurred. One patient in HBP group developed sac infection, and no other complications such as electrode dislocation and heart perforation occurred in both groups.Conclusion HBP is considered the most physiological pacing mode, although it carries the potential risk of increasing in pacing threshold in long-term follow-up.
-
-
表 1 患者基线资料
Table 1. Baseline characteristics
X±S, 例(%) 项目 HBP组
(58例)右室间隔部起搏组(66例) P值 年龄/岁 70.1±10.4 68.1±11.8 0.322 男性 25(43.1) 37(56.1) 0.150 病态窦房结综合征 20(34.5) 21(31.8) 0.753 房室传导阻滞 34(58.6) 36(54.5) 0.648 二度Ⅱ型房室传导阻滞 13(22.4) 10(15.1) 0.352 三度房室传导阻滞 21(36.2) 26(39.4) 心房颤动伴长间歇 4(6.9) 9(13.6) 0.222 高血压 32(55.2) 41(62.1) 0.501 冠心病 24(41.4) 19(28.8) 0.142
下载: 导出CSV
表 2 两组手术前后QRS时限比较
Table 2. QRS duration before and after operation
ms, X±S QRS波时限 HBP组(58例) 右室间隔部起搏组(66例) 术前 95.5±18.5 101.8±26.9 术后 103.6±15.11) 145.2±11.82) 与右室间隔部起搏组比较，1)P < 0.05；与本组术前比较，2)P < 0.05。
下载: 导出CSV
表 3 两组患者随访起搏参数变化
Table 3. Changes of pacing parameters in two groups during follow-up
X±S 项目 HBP组
(58例)右室间隔部起搏组
(66例)心室起搏阈值/(V/0.4 ms) 术后即刻 0.83±0.43 0.72±0.27 术后1年 0.97±0.311) 0.69±0.22 术后2年 1.11±0.391) 0.68±0.21 术后3年 1.28±0.561) 0.70±0.22 心室感知/mV 术后即刻 8.05±4.10 8.98±3.05 术后1年 9.96±6.42 9.03±3.39 术后2年 8.75±5.75 8.88±3.27 术后3年 8.43±5.81 8.87±3.28 心室电极阻抗/Ω 术后即刻 728.7±136.8 681.2±147.2 术后1年 507.3±82.61) 510.7±107.11) 术后2年 499.1±85.51) 496.5±99.41) 术后3年 479.5±72.81) 489.1±98.71) 与术后即刻比较，1)P < 0.05。
下载: 导出CSV
-
[1] Naqvi TZ, Chao CJ. Adverse effects of right ventricular pacing on cardiac function: prevalence, prevention and treatment with physiologic pacing[J]. Trends Cardiovasc Med, 2023, 33(2): 109-122. doi: 10.1016/j.tcm.2021.10.013
[2] Hussain MA, Furuya-Kanamori L, Kaye G, et al. The effect of right ventricular apical and nonapical pacing on the short-and long-term changes in left ventricular ejection fraction: a systematic review and meta-analysis of Randomized-Controlled Trials[J]. Pacing Clin Electrophysiol, 2015, 38(9): 1121-1136. doi: 10.1111/pace.12681
[3] Galand V, Martins RP, Donal E, et al. Septal versus apical pacing sites in permanent right ventricular pacing: The multicentre prospective SEPTAL-PM study[J]. Arch Cardiovasc Dis, 2022, 115(5): 288-294. doi: 10.1016/j.acvd.2021.12.007
[4] Sharma PS, Vijayaraman P, Ellenbogen KA. Permanent His bundle pacing: shaping the future of physiological ventricular pacing[J]. Nat Rev Cardiol, 2020, 17(1): 22-36. doi: 10.1038/s41569-019-0224-z
[5] Jastrzębski M. Physiologic differentiation between selective his bundle, nonselective his bundle and septal pacing[J]. Card Electrophysiol Clin, 2022, 14(2): 151-163. doi: 10.1016/j.ccep.2021.12.009
[6] Beer D, Subzposh FA, Colburn S, et al. His bundle pacing capture threshold stability during long-term follow-up and correlation with lead slack[J]. Europace, 2021, 23(5): 757-766. doi: 10.1093/europace/euaa350
[7] 张洁, 吴冬燕, 何乐, 等. 不同起搏部位的心室电机械同步性分析[J]. 临床心血管病杂志, 2021, 37(5): 440-446. doi: 10.13201/j.issn.1001-1439.2021.05.010
[8] Kronborg MB, Mortensen PT, Poulsen SH, et al. His or para-His pacing preserves left ventricular function in atrioventricular block: a double-blind, randomized, crossover study[J]. Europace, 2014, 16(8): 1189-1196. doi: 10.1093/europace/euu011
[9] Huang W, Su L, Wu S, et al. Long-term outcomes of His bundle pacing in patients with heart failure with left bundle branch block[J]. Heart, 2019, 105(2): 137-143. doi: 10.1136/heartjnl-2018-313415
[10] Sharma PS, Naperkowski A, Bauch TD, et al. Permanent his bundle pacing for cardiac resynchronization therapy in patients with heart failure and right bundle branch block[J]. Circ Arrhythm Electrophysiol, 2018, 11(9): e006613. doi: 10.1161/CIRCEP.118.006613
[11] Archontakis S, Sideris K, Laina A, et al. His bundle pacing: A promising alternative strategy for anti-bradycardic pacing-report of a single-center experience[J]. Hellenic J Cardiol, 2022, 64: 77-86. doi: 10.1016/j.hjc.2021.10.005
[12] Glikson M, Nielsen JC, Kronborg MB, et al. 2021 ESC Guidelines on cardiac pacing and cardiac resynchronization therapy[J]. Europace, 2022, 24(1): 71-164. doi: 10.1093/europace/euab232
[13] Koniari I, Gerakaris A, Kounis N, et al. Outcomes of atrioventricular node ablation and pacing in patients with heart failure and atrial fibrillation: from cardiac resynchronization therapy to his bundle pacing[J]. J Cardiovasc Dev Dis, 2023, 10(7): 110.
[14] Takahashi M, Kujiraoka H, Arai T, et al. New-onset atrial high-rate episodes between his bundle pacing and conventional right ventricular septum pacing in patients with atrioventricular conduction disturbance[J]. J Interv Card Electrophysiol, 2023, 11: 110.
[15] Abdelrahman M, Subzposh FA, Beer D, et al. Clinical outcomes of his bundle pacing compared to right ventricular pacing[J]. J Am Coll Cardiol, 2018, 71(20): 2319-2330. doi: 10.1016/j.jacc.2018.02.048
[16] Zaidi SMJ, Sohail H, Satti DI, et al. Tricuspid regurgitation in His bundle pacing: A systematic review[J]. Ann Noninvasive Electrocardiol, 2022, 27(6): e12986. doi: 10.1111/anec.12986
[17] Pestrea C, Cicala E, Gherghina A, et al. His bundle pacing in nodal versus infranodal atrioventricular block: a mid-term follow-up study[J]. Open Heart, 2023, 10(2): 110.
[18] 顾敏, 华伟, 刘曦, 等. 三尖瓣环显像技术指导下的远端希氏束起搏[J]. 中华心律失常学杂志, 2021, 25(5): 379-384.
[19] Marcantoni L, Centioni M, Pastore G, et al. Conduction system pacing in difficult cardiac anatomies: Systematic approach with the 3D electroanatomic mapping guide[J]. Indian Pacing Electrophysiol J, 2023, 23(6): 177-182. doi: 10.1016/j.ipej.2023.08.006
[20] Perino AC, Wang PJ, Lloyd M, et al. Worldwide survey on implantation of and outcomes for conduction system pacing with His bundle and left bundle branch area pacing leads[J]. J Interv Card Electrophysiol, 2023, 66(7): 1589-1600. doi: 10.1007/s10840-022-01417-4
[21] Teigeler T, Kolominsky J, Vo C, et al. Intermediate-term performance and safety of His-bundle pacing leads: A single-center experience[J]. Heart Rhythm, 2021, 18(5): 743-749. doi: 10.1016/j.hrthm.2020.12.031
[22] Bhatt AG, Musat DL, Milstein N, et al. The efficacy of his bundle pacing: lessons learned from implementation for the first time at an experienced electrophysiology center[J]. JACC Clin Electrophysiol, 2018, 4(11): 1397-1406. doi: 10.1016/j.jacep.2018.07.013
[23] 中华医学会心电生理和起搏分会, 中国医师协会心律学专业委员会. 希氏-浦肯野系统起搏中国专家共识[J]. 中华心律失常学杂志, 2021, 25(1): 10-36.
[24] Chung MK, Patton KK, Lau CP, et al. 2023 HRS/APHRS/LAHRS guideline on cardiac physiologic pacing for the avoidance and mitigation of heart failure[J]. Heart Rhythm, 2023, 20(9): e17-e91.
[25] Kircanski B, Boveda S, Prinzen F, et al. Conduction system pacing in everyday clinical practice: EHRA physician survey[J]. Europace, 2023, 25(2): 682-687.
[26] Tan ESJ, Soh R, Boey E, et al. Comparison of pacing performance and clinical outcomes between left bundle branch and his bundle pacing[J]. JACC Clin Electrophysiol, 2023, 9(8 Pt 1): 1393-1403.
[27] 齐鹏, 田颖, 石亮, 等. 希浦系统起搏联合房室结消融治疗多次消融后复发的持续性心房颤动[J]. 临床心血管病杂志, 2021, 37(12): 1121-1125. doi: 10.13201/j.issn.1001-1439.2021.12.011
[28] Christopher S, Christine TE, Thomas D, et al. Outcomes of combined left bundle branch area pacing with atrioventricular nodal ablation in patients with atrial fibrillation and pulmonary disease[J]. Pacing Clin Electrophysiol, 2024, 10: 110.
[29] El Iskandarani M, Golamari R, Shatla I, et al. Left bundle branch area pacing in heart failure: A systematic review and meta-analysis with meta-regression[J]. J Cardiovasc Electrophysiol, 2024, 11: 110.
[30] Huang W, Chen X, Su L, et al. A beginner's guide to permanent left bundle branch pacing[J]. Heart Rhythm, 2019, 16(12): 1791-1796.
[31] Liu P, Wang Q, Sun H, et al. Left bundle branch pacing: current knowledge and future prospects[J]. Front Cardiovasc Med, 2021, 8: 630399.
-
