实时三维斑点追踪技术评价完全性左束支传导阻滞患者左心室收缩功能

何姗姗; 赵宁; 张文华

doi:10.13201/j.issn.1001-1439.2019.12.011

实时三维斑点追踪技术评价完全性左束支传导阻滞患者左心室收缩功能

- 1 南京中医药大学附属医院超声医学科(南京, 210029);
- 2 大连医科大学附属第二医院超声医学科

详细信息

通讯作者: 张文华,E-mail:zhangwenhua686@163.com

中图分类号: R541.7

收稿日期: 2019-04-02

Evaluation of left ventricular systolic function in patients with complete left bundle branch block by real-time three-dimensional speckle tracking

- 1 Department of Ultrasound, Affiliated Hospital of Nanjing University of Chinese Medicine, Nanjing, 210029, China;
- 2 Department of Ultrasound, the Second Hospital of Dalian Medical University

More Information

Corresponding author: ZHANG Wenhua, E-mail: zhangwenhua686@163.com

Received Date: 02 April 2019

摘要

摘要: 目的:应用实时三维斑点追踪技术对完全性左束支传导阻滞(CLBBB)患者左心室整体及局部收缩功能进行评价。方法:选取孤立性CLBBB患者35例,根据左心室射血分数(LVEF)将其分为A组(LVEF≥50%,18例)和B组(LVEF<50%,17例)。另选取30例健康成年人为对照组。采集各组二维超声数据,采用Simpson法测定LVEF。记录并比较各组三维斑点追踪技术测量的三维应变数据:左心室整体纵向收缩期峰值应变(LVGLS)、左心室整体环向收缩期峰值应变(LVGCS)、左心室整体径向收缩期峰值应变(LVGRS)、左心室整体面积收缩期峰值应变(LVGAS),以及各组间左心室心肌基底段、中间段及心尖段三维应变值。采用ROC曲线分析各三维应变参数诊断CLBBB合并心功能减低的敏感性和特异性。结果:与对照组比较,A组与B组LVGLS、LVGRS、LVGCS、LVGAS均减低,差异有统计学意义(均P<0.05);与A组比较,B组LVGLS、LVGRS、LVGCS及LVGAS均减低,差异有统计学意义(均P<0.05)。各组左心室基底段、中间段、心尖段局部三维心肌应变数值均呈递减改变,差异均具有统计学意义(均P<0.05)。ROC曲线分析结果显示,各参数诊断CLBBB合并心功能减低的曲线下面积为0.805~0.910,准确性较好,其中LVGLS的敏感性(96.4%)及特异性(76.7%)高于其他应变参数。结论:CLBBB患者左心室心肌不协调运动,主要以前壁及前间隔的改变为主;左心室不协调运动导致左心室整体及局部心肌功能减低。实时三维斑点追踪技术可以早期、敏感、准确地评价CLBBB患者的左心功能,其中LVGLS更为敏感。
- 实时三维斑点追踪技术 /
- 完全性左束支传导阻滞 /
- 室性心律失常 /
- 左心功能
Abstract: Objective:To evaluate the global and regional left ventricle systolic function in patients with complete left bundle branch block(CLBBB) by real-time three-dimensional spot tracking technique.Method:Thirty-five cases with isolated CLBBB were divided into two groups according to left ventricular ejection fraction(LVEF):group A(LVEF≥50%,n=18)and group B(LVEF<50%,n=17).Other 30 healthy adults were included into control group.Two-dimensional ultrasonic parameters were measured.LVEF was tested by Simpson method.Real-time three-dimensional echocardiography were used to determine following parameters in three groups:left ventricular global longitudinal strain(LVGLS),left ventricular global circumferential strain(LVGCS),left ventricular global radial strain(LVGRS),left ventricular global area strain(LVGAS),and threedimensional strain values of the basal,middle and apical segments of left ventricular myocardium.ROC curve was used to analyze the sensitivity and specificity of three-dimensional strain parameters in the diagnosis of CLBBB with cardiac dysfunction.Result:Compared with control group,LVGLS,LVGRS,LVGCS,and LVGAS were significantly decreased in group A and group B(all P<0.05);Compared with group A,LVGLS,LVGRS,LVGCS and LVGAS were significantly decreased in group B(all P<0.05).All three-dimensional strain values of the basal,middle and apical segments of left ventricular myocardium were decreased successively with significant differences(all P<0.05).ROC curve analysis showed that the area under the curve of three-dimensional strain parameters in the diagnosis of CLBBB with cardiac dysfunction were 0.805-0.910,and the accuracy was good.The sensitivity(96.4%)and specificity(76.7%)of LVGLS were higher than other strain parameters.Conclusion:The left ventricular myocardial motion is not coordinated in CLBBB patients,mainly including antetheca and front interval changes,which result in the global and regional myocardial dyfunction of left ventricular.Three-dimensional speckle tracking can be used to evaluate left ventricular systolic function in CLBBB patients,sensitively and accurately.LVGLS is a sensitive parameter.
- real-time three-dimensional echocardiography /
- ventricular arrhythmia /
- left bundle branch block disease /
- left ventricular function

HTML全文

参考文献(12)

[1]	Li GY,Wang YH,Guan ZY,et al.Effect of septal flash on right ventricular systolic function in Ieft bundle-branch block patients with preserved left ventricular ejection fraction[J].Sci Rep,2017,7(1):5936.
[2]	王亚萍,田新桥,李爱丽.2D-STI在CLBBB患者左心室功能及同步性评价中的应用[J].重庆医学,2019,48(10):1693-1696.
[3]	Forsey J,Benson L,Rozenblyum E,et al.Early changes in apical rotation in genotype positive children with hypertrophic cardiomyopathy mutations without hypertrophic changes on two-dimensional imaging[J].J Am Soc Echocardiogr,2014,27(2):215-221.
[4]	Breithardt G,Breithardt OA.Left bundle branch block,an old-new entity [J].J Cardiovasc Transl Res,2012,5(2):107-116.
[5]	Dogan C,Bayram Z,Candan O,et al.Prediction of infarct size using two-dimensional speckle tracking echocardiography in acute myocardialinfarction [J].Echocardiography,2017,34(3):376-382.
[6]	蔡璐,尹立雪.超声斑点追踪技术评价扩张型心肌病左心室心肌功能研究进展[J].中华医学超声杂志(电子版),2018,15(3):161-165.
[7]	Hayat D,Kloeckner M,Nahum J,et a1.Comparison of real-time three-dimens ional speckle tracking to magnetic resonance imaging in patients with coronary heart disease[J].Am J Cardiol,2012,109(2):180-186.
[8]	Duan F,Xie M,Wang X,et al.Preliminary clinical study of left,ventricular myocardial strain in patients with non-ischemic dilated cardiomyopathy by three-dimensional speckle tracking imaging[J].Cardiovasc Ultrasound,2012,10:8.
[9]	史静,潘翠珍,舒先红,等.二维斑点追踪显像技术定量评价正常成年人左心肌分层应变[J].中华超声影像学杂志,2015,24(5):378-381.
[10]	Hasselberg NE,Haugaa K,Sarvari SI,et al.Left ventricular global longitudinal strain correlates to diastolic function and reduced exercise capacity in patients with preserved ejection and ejection fraction[J].J Am Coll Cardiol,2013,61(10):819-819.
[11]	邵宏增,孙品,张芬,等.二维应变超声成像对心力衰竭病人再同步化治疗后左心室功能评价[J].青岛大学医学院学报,2016,52(4):390-391,395.
[12]	Akhabue E,Seok CP,Pinney S,et al.Usefulness of speckle tracking strain echocardiography for assessment of risk of ventricular arrhythmias after placement of a left ventricular assist device[J].Am J Cardiol,2017,120(9):1578-1583.
