Shark fin sign: an electrocardiogram patter of acute ST segment elevation myocardial infarction with left main occlusion
-
摘要: 鲨鱼鳍征是一种与冠状动脉(冠脉)左主干闭塞引起的急性心肌梗死(AMI)相关的高危心电图改变，其特征是QRS波、ST段与T波融合形成R波，形态酷似鲨鱼鳍。该特征心电图与患者高危猝死相关。左主干闭塞患者大部分在院前即发生死亡，较难采集到一手心电图资料，现报道1例经冠脉造影证实为左主干闭塞且心电图呈鲨鱼鳍样改变的AMI患者，以提高临床对鲨鱼鳍征心电图改变的认识，减少漏诊和误诊。Abstract: The shark fin sign is a high-risk electrocardiogram(ECG) pattern associated with acute myocardial infarction(AMI) resulting from occlusion of the left main(LM) coronary artery, which is characterized by the fusion of QRS wave, ST segment, and T wave into a giant R wave resembles the shape of a shark's fin and links to a heightened risk of sudden death in patients. It is difficult to obtain firsthand ECG of patients with LM occlusion, because of the high mortality rate before entering the hospital. This is a case study involving an AMI patient with confirmed LM occlusion by coronary angiography performed the shark fin sign pattern in ECG, which is aimed to enhance understanding of the pattern and reduce missed diagnosis or misdiagnosis.
-
Key words:
- shark fin sign /
- giant R wave /
- λ wave /
- acute myocardial infarction /
- left main occlusion
-
-
[1] 李海蓬, 张健. 血运重建策略对左主干病变所致急性心肌梗死患者预后的影响[J]. 临床心血管病杂志, 2022, 38(4): 303-307. https://lcxxg.whuhzzs.com/article/doi/10.13201/j.issn.1001-1439.2022.04.010
[2] 李俊峡, 田新利. 左主干闭塞的心电图表现[J]. 中华心脏与心律电子杂志, 2017, 5(2): 83-86.
[3] 谢雪萍, 郑周玲. 年轻患者Wellens综合征的T波动态演变1例[J]. 临床心血管病杂志, 2023, 39(9): 738-740. https://lcxxg.whuhzzs.com/article/doi/10.13201/j.issn.1001-1439.2023.09.015
[4] Janaki Rami Reddy M, Garg J. Shark fin sign[J]. J Arrhythm, 2021, 37(5): 1362-1363. doi: 10.1002/joa3.12594
[5] Escabi-Mendoza J, Diaz-Rodriguez PE, Silva-Cantillo RD. Shark Fin Occlusive Myocardial Infarction ECG Pattern Post-cardiac Arrest Misinterpreted As Ventricular Tachycardia[J]. Cureus, 2023, 15(5): e38708.
[6] Cipriani A, D'Amico G, Brunello G, et al. The electrocardiographic"triangular QRS-ST-T waveform"pattern in patients with ST-segment elevation myocardial infarction: Incidence, pathophysiology and clinical implications[J]. J Electrocardiol, 2018, 51(1): 8-14. doi: 10.1016/j.jelectrocard.2017.08.023
[7] 郑晓波, 樊静静, 王广强, 等. λ波是冠心病患者发生恶性心律失常的新预测因子[J]. 内科急危重症杂志, 2021, 27(6): 462-467, 496.
[8] 刘芳, 向芝青, 田君华. 变异型心绞痛呈巨R波型ST段抬高1例[J]. 心电与循环, 2015, 34(1): 49-50.
[9] 江聪美. ST段改变表现的猝死预警心电图 4例分析[J]. 心电与循环, 2018, 37(4): 277-280.
[10] Wang Y, Guo W, Ma JY. Takotsubo cardiomyopathy and giant r wave syndrome mimicking acute myocardial infarction[J]. Medicine, 2019, 98(9): e14677. doi: 10.1097/MD.0000000000014677
[11] Elikowski W, Szczęs ' niewski P, Fertała N, et al. Shark fin ECG pattern a patient with Takotsubo syndrome-case study and literatire review[J]. Polski Merkuriusz Lekarski, 2023, 51(5): 575-580. doi: 10.36740/Merkur202305119
-
